In-chassis installation

Drawbeam

Drawbeam

VBG’s drawbeams are suitable for all types of trailers. The drawbeams are mounted using VBG’s endplate kits. All drawbeams are surface-treated with VBG’s unique surface treatment.

VBG Drawbeam DB-C7

VBG Drawbeam DB-C7

DB C7 is a vehicle-customised drawbeam for central or semi-underslung installation. It is supplied with a hole pattern corresponding to the respective truck manufacturer's specifications and requireme...
VBG Drawbeam DB 75V-2

VBG Drawbeam DB 75V-2

Drawbeam DB 75V-2 is designed for trailers with high front axle loads. It is also suitable for dollies and heavy centre-axle trailers.

VBG Drawbeam DB 75V-3

VBG Drawbeam DB 75V-3

Drawbeam DB 75V-3 is designed for High Capacity Transport (HCT) vehicles. It is also suitable for dollies and heavy centre-axle trailers. The drawbeam is mounted underslung with the EDH-4 endplate kit...
VBG Drawbeam DB 260D

VBG Drawbeam DB 260D

DB 260D is a drawbeam intended for heavy trailer loads. The drawbeam has 10 holes for coupling installation, and is fitted centrally in the chassis frame. The length of the drawbeam can be adjusted w...
VBG Drawbeam AMS-MFC

VBG Drawbeam AMS-MFC

A specially designed drawbeam system for central installation of the VBG MFC fully automatic coupling. The drawbeam system is supplied with spacers (if the truck frame has inner liner) and a screw ki...
VBG Drawbeam TB 30D

VBG Drawbeam TB 30D

TB 30D is a drawbeam intended for ball couplings, alternatively automatic couplings with flat connecting flange. The drawbeam can be installed centrally in the vehicle frame or completely underslung t...

Screw kit

Always use the right type of screw with the correct screw length. This is a matter of safety, since an incorrect screw length can affect the strength of the system! Also choose high-quality screws for optimal corrosion protection and functionality. VBG screw kits are surface treated with consideration given to the surrounding materials, and provide corrosion protection in salt-spray tests for up to twice as long as zinc-iron.

VBG Screw kit

VBG Screw kit

Always use the right type of screw with the correct screw length. This is a matter of safety, since an incorrect screw length can affect the strength of the system! Also choose high-quality screws for...

Spacer

Spacer

Spacer

When selecting spacers for use between the endplate and drawbeam, a maximum of 2 spacers is permitted on each side with a maximum total thickness of 20 mm. This spacer fits DB drawbeams

Accessories

Brackets for power and air, left

Brackets for power and air, left

VBG’s system of brackets is adapted to most electrical and pneumatic connectors on the market. The brackets are mounted on the drawbeams and can be used in several different positions. Flexible syste...
Brackets for power and air, right

Brackets for power and air, right

VBG’s system of brackets is adapted to most electrical and pneumatic connectors on the market. The brackets are mounted on the drawbeams and can be used in several different positions. Flexible syste...
Brackets for power and air, underlying

Brackets for power and air, underlying

VBG’s system of brackets is adapted to most electrical and pneumatic connectors on the market. The brackets are mounted on the drawbeams and can be used in several different positions. Flexible system...

Options

Mounting coupling on drawbeam

Mounting coupling on drawbeam

Couplings, endplates, and other equipment can be supplied factory-fitted to the beam. All you need to do is screw the finished system to the vehicle chassis. This saves both time and work. In addition...
